Heavy Weight Butt Hinges with Ball Bearing

Heavy weight butt hinges with ball bearings are used where a door, lid, cover, or access panel needs strong support and smoother rotation under repeated use. OEM applications may include industrial enclosures, appliance doors, transportation access panels, medical casegoods, commercial cabinets, and specialty equipment. Mansfield can engineer the hinge around load, geometry, material, finish, and production requirements.

Mansfield Engineered Components does not primarily operate as a standard catalog hardware supplier. The company focuses on custom-engineered hinges and motion control components for OEM programs. That approach is useful when an off-the-shelf hinge cannot meet the product’s load rating, motion feel, space envelope, finish, target cost, or long-term production requirements.

Yes. Mansfield designs custom hinge programs around each OEM application, including hinge geometry, leaf size, pin design, bearing support, material selection, finish, mounting method, and performance targets. The engineering team can prototype and test designs in-house before production tooling, helping confirm fit, motion, durability, and manufacturability before full program launch.

Material selection depends on the application environment, load, finish requirements, and cost target. Mansfield’s capabilities include cold-rolled steel, stainless steel, aluminum, spring steel, and specialty alloys for demanding conditions. Stainless steel may be appropriate for corrosion resistance, medical casegoods, or food-contact environments, while aluminum may support weight-sensitive transportation applications.

Mansfield supports OEM production programs ranging from approximately 5,000-unit specialty runs to 5,000,000+ components per program. The company ships over 250,000 motion control components every week and uses progressive die stamping, flexible assembly lines, strategic inventory, and release-based shipping to support both high-volume and lower-volume specialty programs.

Pricing is quoted per program and depends on design complexity, materials, tolerances, tooling, validation requirements, finish, assembly needs, and production volume. Mansfield applies value engineering to help meet the OEM’s target unit economics. Tooling, prototyping, and engineering support are typically considered during program development rather than priced as a generic catalog item.

Yes. Mansfield provides production transition and resourcing support for discontinued suppliers, closed factory divisions, end-of-life supplier relationships, offshore supply issues, and reshoring scenarios. Services can include tooling transfer, line relocation, first-article inspection, production validation, and value engineering while maintaining required form, fit, and function compatibility.

To begin an RFQ, provide available drawings, application requirements, expected load, motion arc, mounting constraints, material or finish needs, annual volume, target cost, and launch timing. Mansfield’s team can review the requirements, identify engineering considerations, discuss prototyping or tooling needs, and develop a custom quote for the OEM program.
